1995 Dusenbery Rotary Shear Slitter
Parkinson Technologies
Model Overview
The Dusenbery Model 475 Rotary Shear Slitter is a precision web processing system designed for controlled material separation in research and manufacturing applications. ***- Estimated Hours of Operation: 37,000 hours.*** ## Key Features - Accommodates web widths up to 500mm with precision edge co...
Technical Specifications
No specifications available
Similar models
2223
4-Lane Pilot Electrode Slitter
Electrode Slitter Machine provides four-lane wheel-type knife cutting with EPC control for electrode width conversion and material handling. ## Key Features - Four-lane carbide knife cutting with ±0.1mm accuracy and <20μm burr specification - Wheel-type knife system with AC reversible motor drive and fixed block configuration - EPC system with speed control motor for electrode positioning and tracking - Dual friction shaft rewinders with automated pressure regulation and position guides - Photo sensor monitoring for foil break detection across all four lanes - Mitsubishi PLC control with Proface 7" touchscreen interface - 350mm maximum foil width with 5 m/min processing speed capability System includes integrated unwinder with 3" air shaft and automated tension control. ## Additional Documentation (NDA Required) - Detailed Process Specifications ## Key Technical Specifications |||| |:--|:--|:--| |**Maximum Foil Width**|350 mm|| |**Machine Speed**|5 m/min maximum|| |**Slitting Lanes**|4 lanes|| |**Slitting Accuracy**|±0.1 mm|| |**Burr Specification**|<20 μm|| |**Position Accuracy**|±0.1 mm|| |**Maximum Spool Size**|Ø300 mm|| |**Knife Material**|Carbide|| |**Knife Configuration**|Fixed Block Type|| |**Tension Control**|Powder clutch & dancer roll|| |**Unwinder Shaft**|3" air shaft|| |**Rewinder Shafts**|3" friction shaft (2 sets)||
Prismatic Electrode Inspection & Cutting System
High-throughput prismatic electrode inspection system designed for automated quality control in lithium-ion battery manufacturing, integrating cutting, inspection, and material handling capabilities for multiple electrode chemistries. ## Key Features - Precision cutting system with closed-loop control achieving ±0.3mm accuracy and ±0.1mm correction capability (CPK >1.33) - High-speed processing capability of 70 meters per minute with integrated CCD defect detection - Versatile material handling system supporting ferrous lithium phosphate, graphite water, and ternary systems with thickness range of 50-200μm - Dual-format processing capability for single and double tab configurations, with tab heights adjustable from 5-35mm - Advanced material handling system supporting roll-to-roll processing with 700mm maximum roll diameter and 500kg weight capacity - Comprehensive dust and waste collection system integrated into the equipment design ## Key Technical Specifications |||| |:--|:--|:--| |**Core Diameter**|6in|| |**Cutting Accuracy**|+/- 0.3mm|| |**Processing Speed**|70m/min|| |**Tab Height Range**|5-35mm|| |**Maximum Roll Length**|600mm|| |**Material Width Range**|150-500mm|| |**Maximum Roll Diameter**|700mm|| |**Control Loop Precision**|+/- 0.1mm|| |**Maximum Material Weight**|500kg|| |**Material Thickness Range**|50-200μm|| |**Control Systems**|Omron|| |**Standards**|Built to GB Standards|| Serial Number: 10-4372/4052
