Summary

The SMTCL STC34100 is a CNC pipe threading lathe engineered for precision machining of cylindrical and conical threads on pipes, utilizing a FANUC control system. Designed primarily for threading applications in the petroleum, metallurgical, chemical, and hydropower/geology sectors, it supports both metric and British system threads and can perform a wide range of turning operations on shaft and disc components. Key differentiators include compatibility with large-diameter oil industry pipes and the capability to achieve IT6-IT7 machining accuracy with fine surface finishes.

Key Capabilities

• CNC-controlled threading of cylindrical and conical oil pipes
• Supports both metric and British thread standards
• Capable of general turning, including complex shapes and internal/external threads
• Machining of drill pipes, drill collars, casing pipes, and petroleum casing pipes
• Achieves surface roughness up to Ra1.3μm and IT6-IT7 accuracy
• Suitable for large-scale and production applications in petroleum and related industries

Key Specifications
