Dn Solutions DEM 4000 | 3-Axis Vertical Machining CenterAvailable
Save
Share
Dn Solutions
To be updated
Condition: New
Scale: Production
Status: Ready-to-Ship
Ships From: USA
Product Description
Summary
The DEM 4000 is a 3-axis vertical machining center engineered for material removal operations using rotary cutting tools. It delivers precise, high-speed milling and drilling within a limited workspace, supported by a rigid structural design and ISO #40 spindle. Differentiators include an 8000 r/min spindle, X/Y/Z travels of up to 550/400/450 mm, and two available tool magazine configurations.
Key Capabilities
- 3-axis linear motion for multi-face machining
- Max spindle speed of 8000 r/min for high-speed cutting
- Table supports up to 400 kg workpieces (650 x 400 mm area)
- Optional 20-tool (ARM) or 16-tool (ARMLESS) automatic magazine
- Rapid traverse rate of 24 m/min on all axes
Key Specifications
| Parameter | Value | Unit |
|---|---|---|
| X-Axis Travel | 550 | mm |
| Y-Axis Travel | 400 | mm |
| Z-Axis Travel | 450 | mm |
| Max. Spindle Speed | 8000 | r/min |
| Max. Table Load | 400 | kg |
| Table Size (Length x Width) | 650 x 400 | mm |
| Tool Magazine Capacity | 20 (ARM) / 16 (ARMLESS) | - |
| Machine Weight | 3100 | kg |
