Makino V77 Graphite | High-Speed Graphite Machining CenterAvailable
Save
Share
Makino
To be updated
Condition: New
Scale: Production
Status: Ready-to-Ship
Ships From: USA
Product Description
Summary
The Makino V77 Graphite is designed for high-speed, high-accuracy machining of graphite materials. It features a low-vibration, high-speed spindle and advanced control systems for precise milling of complex cavities and cores, making it well suited to graphite electrode and mold component manufacturing. Key differentiating characteristics include the proprietary GI.5 control, operator-friendly GUI, and the SGI.5 servo control for minimized cycle times.
Key Capabilities
- High-speed spindle optimized for graphite machining
- Advanced Makino Professional 6 control with large touchscreen interface
- Proprietary GI.5 and SGI.5 control systems for reduced cycle times on complex shapes
- Handles large graphite workpieces up to 2,500 kg
- Supports optional automatic tool changer with multiple capacity options
Key Specifications
| Parameter | Value | Unit |
|---|---|---|
| Table Size | 1,400 x 700 | mm |
| X Travel | 1,200 | mm |
| Y Travel | 700 | mm |
| Z Travel | 640 | mm |
| Maximum Workpiece | 1,400 x 700 x 550 | mm |
| Maximum Payload | 2,500 | kg |
| Spindle Speed | 20,000 (30,000 opt) | RPM |
| Spindle Taper | CAT40 (HSK-A63, HSK-F63) | - |
| Rapid Traverse | 20,000 | mm/min |
| Cutting Feedrate | 20,000 | mm/min |
| ATC Capacity | 30 (40, 80 opt) | tools |
| Tool to Tool Change Time | 5 | sec |
| Max Tool Diameter | 120 | mm |
| Max Tool Weight | 8 | kg |
