Okamoto UPZ-8 20Li | Ultra-High Precision CNC Form GrinderAvailable
Save
Share
Okamoto
To be updated
Condition: New
Scale: Production
Status: Ready-to-Ship
Ships From: USA
Product Description
Summary
The Okamoto UPZ-8 20Li is an ultra-high precision CNC form grinder designed for complex component grinding requiring micron-level accuracy. Its rigid traveling column construction, digital scale feedback, and linear motor drives support repeatable precision positioning and multi-positioning operations. The machine emphasizes small-lot, varied item production with fine incremental control and advanced dressing capabilities.
Key Capabilities
- Ultra-high precision form grinding with minimum increment adjustment of 0.00001"
- Rigid traveling column structure for stability during grinding
- Digital scale feedback for both vertical and cross axes
- Linear motor-driven longitudinal table for high-speed oscillation (up to 500 strokes/min)
- Multi-positioning capability for varied, small lot production
- FANUC 0-iMF CNC with 3 axes and simultaneous 2-axis control
- Support for slit grinding and precise positioning tasks
- Standard 3-point dresser, with optional rotary dresser
Key Specifications
| Parameter | Value | Unit |
|---|---|---|
| Table Size (Width x Length) | 8.7 x 21.7 | in |
| Distance Table to Wheel Bottom | 0.49 ~ 15.6 | in |
| Standard Chuck Size (W x D x H) | 8 x 20 x 3.1 | in |
| Max Table Load (inc. Chuck) | 133 | lbs |
| Feedrate | 3.2 ~ 79 | in/min |
| High Speed Table Oscillation | 500 | strokes/min |
| Minimum Increment | 0.00001 | in |
| Grinding Wheel Spindle Motor | 5 | hp |
| Machine Dimensions (L x W x H) | 91 x 92 x 88 | in |
| Machine Weight | 10,000 | lbs |
