Summary

The Mazak INTEGREX j-400 is a CNC machine designed for both turning and multi-face milling operations in a single setup. By combining a high-capacity milling spindle with versatile multi-axis motion and a dual-spindle configuration, it enables complex machining—including outer diameter, end facing, and diagonal operations—with minimal setups. Key technical characteristics include a B-axis milling spindle capable of indexing from -30° to 190° in 5-degree increments, generous linear travel, and an HSK-A63 tool interface.

Key Capabilities

• Performs turning and multi-face milling in a single setup with "DONE IN ONE" capability
• B-axis milling spindle with 5-degree programmable indexing for complex part geometries
• Dual spindle system for reduced setup time and phase alignment
• Automatic tool changer supporting HSK-A63 tooling and up to 20 tools
• Large work envelope with extended X, Y, and Z-axis travel
• Milling spindle cutting capacity equivalent to small machining centers
• High accuracy coupling on the B-axis for precise indexing
• Tailstock with sufficient stroke for unobstructed setup and operation

Key Specifications
