Summary

The Okamoto OGM-III Series is a CNC cylindrical grinder designed for precision grinding of multiple diameters in a single setup. Its primary function is external cylindrical grinding, delivering high positional accuracy and efficiency for batch or one-off part production. Distinctive features include the ability to grind up to 10 different diameters in any sequence, a rigid T-shaped casting, and a Fanuc MDI control with touch screen conversational programming.

Key Capabilities

• Simultaneous grinding of up to 10 different diameters in one setup
• CNC operation with touch screen conversational Fanuc MDI control
• T-shaped main casting and fully supported table for rigidity
• Double V slideways for straightness and accuracy
• Rigid spindle with precision angular contact bearings
• Workhead spindle speeds adjustable between 100 and 500 rpm

Key Specifications
