Summary

The Dn Solutions PUMA 5100LMB is a CNC Y-axis horizontal turning center designed for heavy-duty machining of large and complex workpieces, including long pipes and components for the oil and gas industry. It supports single-setup machining and incorporates live tooling and a substantial Y-axis stroke, facilitating productivity in the turning and milling of large diameter parts. Distinguishing features include a maximum turning length of over 2 meters, a 21-inch chuck, and a 200 mm Y-axis stroke for multi-axis operations.

Key Capabilities

• CNC turning and milling in a single setup, including complex parts
• Accommodates workpieces up to 2,002 mm in length and 650 mm in diameter
• Capable of machining large diameter pipes with 375 mm spindle through-hole
• 12-station tool turret with live tooling up to 4,000 RPM
• Heavy duty cutting enabled by high spindle torque and power
• Enables advanced thread machining with wide application support

Key Specifications
