Summary

The Lynx 2600Y is a CNC turning center designed for precision turning, grooving, and milling of cylindrical components. It enables simultaneous turning and milling operations through integrated live tooling and Y-axis capability, supporting flexible production of complex parts. Key features include a 10-inch chuck, 12-station turret, and a high-torque spindle for efficient heavy-duty machining.

Key Capabilities

• CNC turning with Y-axis for off-center and complex milling operations
• Integrated 12-station servo-driven turret with live tooling (rotary tool speed up to 6000 RPM)
• Max turning diameter of 380 mm and turning length up to 610 mm
• High-torque spindle (403 N·m) supports heavy cutting
• Rapid traverse rates of 30 m/min for X and Z axes
• Slideway cover design for chip and coolant management

Key Specifications
